FUTURE DESIGN CONTROLS introduces the MCT4 1/4 DIN Multi-Loop Controller.
THE FIRST 1/4 DIN MULTI-LOOP CONTROLLER THAT OPERATES LIKE YOUR SMARTPHONE OR TABLET
Simplicity
Complete setup in minutes. The MCT4 is programmable from the touch screen right out of the box with one-touch import/export of confuguration and profiles.
Flexibility
Up to 3 loops of PID control, 1 loop may be an FM limit. Up to 19 programmable alarms (9 relays, 10 soft) for flexible process control.
Connectivity
Email (SSL/TLS), SMS, FTP, FileWeb, DataWeb, Virtual Network Computing (VNC), NTS < Web page, Serial Modbus, TCP/IP Modbus. Remote View/Control using PC, Tablet or Smartphone via VNC are all standard.
MCT4 DIN CONTROLLER OVERVIEW
MCT4 APPLICATION STORY
Additional Features
- Dynamic screens/options configuration
- Automated program entry and control
- Data logging
- Historical data viewer
- Chart trend view
- User-based security
- Full audit trail entries
- Digital signatures
- Mechanical and soft alarms
- 11 supported languages
- National time server connectivity
- Meets the requirements for data aquisition for CFR21 Part 11 & AMS 2750E
Specifications
Power
90-250 VAC
11-26 VAC/VDC
Display
4.3" TFT color touch display
Resolution: 480 X 272
Colors: 65,536
Display lifetime hours (nominal): 30,000
Type: Resistive Analog - IP65
Display Processor
PV210 CPU/1GHZ
Dimensions/Panel Cutout
122(W) x 100(H) x 122.85(D) mm
Panel Cutout: 91(W) x 91(H) mm
Data Storage
256MB Internal Flash - 4GB SD (SLC)
Connectivity
Serial: Com1 (RS232), Com2 (232./485) Ethernet: 10\100 baseT - USB: 1 host Modbus Master and Slave Protocols
Storage Temperature
-20 to 60 C
Operating Temperature
0 to 50 C
Humidity
10% to 90%, no condensation
Shock
3 shocks per direction 11ms 10g
Vibration
10 to 25.7 Hz: 0.75mm amplitude
25.7 to 150Hz: 1g 1oct/min. 10 sweeps
Insulation
20M ohms minimum (500VDC)
Dielectric Strength
2300Vac 50/60 Hz for 1 minute between power terminal and earth
Approval Standards
NEMA 4x/IP65, UL, CUL, CE, RoHS, WEEE
